MinIO Operator

The MinIO Operator provides easy to run MinIO Tenant on Kubernetes. We have provided cluster-wide MinIO Operator for easy deployment of MinIO S3 object storage servers. The MinIO Operator defines a kind of Tenant that ensures the existence of a object storage. Full documentation about its structure is available here. The official manual for creating an example MinIO tenant can be found here. For your convenience, we provide some working examples below, divided into sections.

Deploying a single instance

You can start with an example instance, which is suitable for testing. This example creates a resource Tenant defined by the installed Minio operator. You can download the example here.

apiVersion: minio.min.io/v2
kind: Tenant
metadata:
  name: myminio
spec:
  ## Create users in the Tenant using this field. Make sure to create secrets per user added here.
  ## Secret should follow the format used in `minio-creds-secret`.
  users:
    - name: myminio-user-secret
  ## Specification for MinIO Pool(s) in this Tenant.
  pools:
    ## Servers specifies the number of MinIO Tenant Pods / Servers in this pool.
    ## For standalone mode, supply 1. For distributed mode, supply 4 or more.
    ## Note that the operator does not support upgrading from standalone to distributed mode.
    - servers: 4
      ## custom pool name
      name: pool-0
      ## volumesPerServer specifies the number of volumes attached per MinIO Tenant Pod / Server.
      volumesPerServer: 2
      ## This VolumeClaimTemplate is used across all the volumes provisioned for MinIO Tenant in this Pool.
      volumeClaimTemplate:
        metadata:
          name: data
        spec:
          accessModes:
            - ReadWriteOnce
          resources:
            requests:
              storage: 2Gi
      ## Configure Pod's security context
      securityContext:
        runAsNonRoot: true
        fsGroup: 1000
        runAsUser: 1000
        runAsGroup: 1000
      ## Configure container security context
      containerSecurityContext:
        runAsNonRoot: true
        privileged: false
        runAsUser: 1000
        runAsGroup: 1000
        allowPrivilegeEscalation: false
        capabilities:
          drop:
          - ALL
        seccompProfile:
          type: "RuntimeDefault"

This example also requires to deploy secret for the user. You can download the secret example.

apiVersion: v1
kind: Secret
metadata:
  name: myminio-user-secret
type: Opaque
data:
  CONSOLE_ACCESS_KEY: Y29uc29sZQ== # "console", base64 encoding
  CONSOLE_SECRET_KEY: Y29uc29sZTEyMw== # "console123", base64 encoding

To specify and encode/decode own access_key (username) and secret_key (password), you can use the following commands:

# encode
echo -n "securepassword" | base64
# decode
echo -n "c2VjdXJlcGFzc3dvcmQ=" | base64 -d

Run kubectl create -n [namespace] -f example-tenant-secret.yaml -f example-tenant.yaml, you should see pod named myminio-pool-0-0 (possibly similar pods depending on the configuration) running in the specified namespace.

S3 Storage Access

To access the storage from other Pods, you can use myminio-console and myminio-hl services that are automatically created. These services work like DNS names, so you can use them as endpoints for another applications within the Kubernetes cluster. If exposure to another namespace is required, use the full name - e.g. myminio-hl.[namespace].svc.cluster.local.

myminio-console:9443 provides a HTTP web-based console for managing the MinIO
myminio-hl:9000 provides the S3 server connection

Network Policy

To increase security, a network policy can be used to allow network access to the S3 storage only from certain pods. See Network Policy for more information. External access, i.e. access from the public Internet, is disabled by default. However, it is possible to expose the S3 via Load Balancer.

This is an example of a NetworkPolicy applied to the Minio tenant. You can download this example here

apiVersion: networking.k8s.io/v1
kind: NetworkPolicy
metadata:
  name: myminio-np
spec:
  podSelector:
    matchLabels:
      # This NetworkPolicy is applied to the `myminio` Tenant
      app: myminio
  policyTypes:
  - Egress
  - Ingress
  egress:
    # Enables egress communication to the local DNS resolver
  - to:
    - namespaceSelector:
        matchLabels:
          kubernetes.io/metadata.name: kube-system
      podSelector:
        matchLabels:
          k8s-app: kube-dns
    ports:
    - protocol: UDP
      port: 53
    # Enables egress communication to the Minio operator installed in Kubernetes.
  - to:
    - ipBlock:
        cidr: 10.43.0.1/32
    - ipBlock:
        cidr: 10.16.62.14/32
    - ipBlock:
        cidr: 10.16.62.15/32
    - ipBlock:
        cidr: 10.16.62.16/32
    - ipBlock:
        cidr: 10.16.62.17/32
    - ipBlock:
        cidr: 10.16.62.18/32
    ports:
    - port: 6443
      protocol: TCP
  ingress:
    # Enables ingress communication from any Pod to the 9000 and 9443 ports
    # for web management console access and S3 connection
  - from:
    - podSelector: {}
    ports:
    - protocol: TCP
      port: 9000
    - protocol: TCP
      port: 9443

This is an example of a NetworkPolicy applied to a hypothetical application. You can download this example here

kind: NetworkPolicy
apiVersion: networking.k8s.io/v1
metadata:
  name: myapplication-allow-s3
spec:
  podSelector:
    matchLabels:
      # This NetworkPolicy is applied to `myapplication` Pod
      app: myapplication
  policyTypes:
  - Egress
  egress:
    # Enables egress S3 communication from `myapplication` to the `myminio` Tenant
  - to:
    - podSelector:
        matchLabels:
          app : myminio
    ports:
    - protocol: TCP
      port: 9000
